35HDLSAU12
| 制造商: | Switchcraft Inc. |
|---|---|
| 产品类别: | Barrel - Audio Connectors |
| 说明书: | 35HDLSAU12 |
| 描述: | 3.5MM LCK SLD STEREO PLUG .12 GO |
| RoHS状态: | 通过无铅认证 |
| 属性 | 属性值 |
|---|---|
| 制造商 | Switchcraft Inc. |
| 产品类别 | Barrel - Audio Connectors |
| 性别 | Male |
| 系列 | 35HD |
| 特性 | Locking, Sealed, Strain Relief |
| 包括 | 4 pcs - 1 Connector, 1 Handle, 1 Insulator Tube, 1 O-Ring |
| 包装 | Bulk |
| 屏蔽 | Unshielded |
| 体色 | Gold, Black |
| 部分状态 | Active |
| 终止 | Solder Eyelet(s) |
| 螺纹尺寸 | - |
| 信号线路 | Stereo (3 Conductor, TRS) |
| 基体材料 | Copper Alloy |
| 电缆开 | 0.125" ~ 0.150" (3.18mm ~ 3.81mm) |
| 安装方式 | Free Hanging (In-Line) |
| 连接器类型 | Phone Plug |
| 实际的直径 | 0.140" (3.56mm) |
| 面板孔大小 | - |
| 电压,额定 | 250VAC, 140VDC |
| 触点材料 | Copper Alloy |
| 绝缘颜色 | - |
| 内部开关(年代) | Does Not Contain Switch |
| 介电材料 | Copper Alloy |
| 交配长度/深度 | - |
| 额定电流(安培数) | 4A |
| 工作温度 | -20°C ~ 85°C |
| 接触材料-电镀 | Gold |
| 数量的职位/联系人 | 3 Conductors, 3 Contacts |
| 行业认可配合直径 | 3.50mm (0.141", 1/8", Mini Plug) - Headphone |
