To provide wide AC voltage input 90VAC～264VAC
Protections: Short circuit/Over current/Over voltage
Meet 4KV surge immunity level
Meet energy star level V
Electrial Specifications
Input Voltage Range: 90 ～ 264VAC
Input Current: 0.9A
Output Voltage Range: ±5%
Average Efficiency: Meet energy star levelV(V2.0)
MTBF: 50,000 hours at maximum load levels and an ambient temperature of 25℃(in correspondence with MIL-HDBK-217)
Low Standby Power: 0.3W
Environmental Parameter
Operation Temp: 0℃ ～ 40℃
Storage Temp: - 20℃ ～ 60℃
Humidity：5% to 95% non condenising
Saftey Approval
cULus(ITE UL60950)、TUV-GS(ITE EN60950)、CE、CCC(GB4943 2000m Elevation), CB(IEC60950)
Dimensions
118mm (L) ; 53mm (W) ; 31.5mm (H)
Applications
ITE Equipment
Output data
| Model | Voltage （V) | Current (A) | Ripple (mV) | XXX |  115 230 | Av. Eff. (%)Min |
| UE36LCP-XXXYYYSPAZ | 9.00-12 | 0.01- 3.00 | 200 | 090-120 | Y Y | 84.82 |
| 12.1-13 | 0.01-2.67 | 200 | 121-130 | Y Y | 84.62 | |
| 13.1-14 | 0.01-2.57 | 200 | 131-140 | Y Y | 84.80 | |
| 14.1-15 | 0.01-2.40 | 200 | 141-150 | Y Y | 84.78 | |
| 15.1-16 | 0.01-2.25 | 200 | 151-160 | Y Y | 84.78 | |
| 16.1-17 | 0.01-2.11 | 200 | 164-170 | Y Y | 84.79 | |
| 17.1-18 | 0.01-2.00 | 200 | 171-180 | Y Y | 84.78 | |
| 18.1-19 | 0.01-1.89 | 200 | 181-190 | Y Y | 84.80 | |
| 19.1-20 | 0.01-1.80 | 200 | 191-200 | Y Y | 84.78 | |
| 20.1-21 | 0.01-1.71 | 200 | 201-210 | Y Y | 84.80 | |
| 21.1-22 | 0.01-1.63 | 200 | 211-220 | Y Y | 84.80 | |
| 22.1-23 | 0.01-1.56 | 200 | 221-230 | Y Y | 84.80 | |
| 23.1-24 | 0.01-1.50 | 200 | 231-240 | Y Y | 84.82 |
